Handy Talky FTA-750 L YAESU / HT FTA750L

YAESU FTA-750L adalah transceiver Airband inovatif dengan GPS 66 channel untuk navigasi yang andal. Dilengkapi layar LCD besar, perangkat ini mendukung komunikasi penuh pada Band Pesawat, navigasi VOR dan ILS pada Band "NAV", serta waypoint GPS bawaan. Selain itu, FTA-750L memiliki fitur pemantauan cuaca NOAA, kemampuan memprogram hingga 200 saluran memori, dan menu berbasis ikon yang mudah digunakan. Dengan kabel USB yang disertakan, perangkat ini dapat diprogram ulang dengan cepat menggunakan perangkat lunak opsional.

Kelengkapan

-Unit HT

- Baterai HT

- Adaptor Charger

- Desktop Charger

- Antena

- Belt Clip

Fitur:

- Now Meets MIL-STD-810F

- Integrated 66 Channel WAAS GPS receive

- GPS Position Logging operation

- ILS (Localizer & Glide Slope) and VOR Navigation

- Easy to operate menu system

- Huge Dot Matrix LCD display

- 200 Channel Memory bank

- PC Programmable

Spesifikasi:

- Frequency Range:

TX: 118.000 to 136.9916 MHz

RX: 108.000 to 136.9916 MHz (NAV and COM)

161.650 to 163.275 MHz (Weather Channels*)

329.150 to 335.000 MHz (Glide Slope)

- Channel Spacing: 25 kHz/8.33 kHz

- Emission Type: TX: AM; RX: AM & FM (FM: for receiving the Weather Channels)

- Supply Voltage: 6.0 to 9.5 VDC

- Current Consumption (approx.):

300 μA (power off)

80 mA (battery saver on, saver ratio 50 %, GPS on)

110 mA (squelch on, GPS on)

300 mA (receive)

0.9 A (transmit 1.5 W Carrier)

- Temperature Range: +14°F to +140°F (-10°C to +60°C)

- Antenna Connector: BNC Type

- Case Size (W x H x D): 2.4" × 5.2" × 1.3" (62 × 133 × 34 mm) with SBR-39LI

- Weight (approx.): 14.5 oz (410 g) with SBR-39LI, antenna, and belt clip

Receiver:

- Circuit Type: Double-conversion superheterodyne

IFs: 47.25 MHz & 450 kHz

- Sensitivity: Better than 0.8 μV (for 6 dB S/N with 1 kHz, 30 % modulation)

- Selectivity: Better than 8 kHz/–6 dB

- Adjacent CH. Selectivity: Less than 25 kHz/–60 dB

- AF Output (Internal speaker): 0.8 W @ 16 Ohms, 10 % THD

Transmitter:

- Power Output: 5.0 W (PEP), 1.5 W (Carrier Power)

- Frequency Stability: Better than ±1 ppm (+14°F to +140°F [–10°C to +60°C])

- Modulation System: Low Level Amplitude Modulation

- Spurious Emission: > 70 dB below carrier

- Internal Microphone Type: Condenser

  Ext. Mic. Impedance: 150 Ohms
