Handy Talky GP338 MOTOROLA / HT GP 338 | VHF 136-174

MOTOROLA OUTLET RESMI
Kami adalah Master Dealer Motorola indonesia dan menjamin barang kami ASLI Motorola.
Barang dijamin baru (bukan barang bekas atau rekondisi).
Bergaransi Resmi Motorola indonesia selama 1 Tahun dan no seri terregister di Motorola indonesia.
Kalau barang tidak asli, uang akan kembali 100%.
Note : jangan sampai merusak segel, karena Garansi akan Void (tidak berlaku).

GP338 adalah radio komunikasi yang dirancang untuk mereka yang sering bergerak, seperti pembangun, kontraktor, insinyur, dan petugas keamanan. Dilengkapi dengan audio jernih, tampilan identifikasi penelepon, dan layar LCD besar yang memudahkan navigasi, radio ini menawarkan 128 saluran untuk komunikasi cepat. Selain itu, GP338 memungkinkan panggilan telepon dan halaman dari siapa saja, di mana saja, menjadikannya alat penting untuk koordinasi antar kelompok kerja, beroperasi di luar ruangan, berkomunikasi di lingkungan bising, serta dalam situasi darurat atau penegakan hukum.

KELENGKAPAN:
- Unit Radio
- Baterai
- Antena
- Belt Clip
- Charger
- Manual Book

SPESIFIKASI:
- Frequency: (MHz) 29 - 42 / 35 - 50 / 136 - 174 / 330 - 400 / 403 - 470 / 450 - 527
- Channel Capacity: GP328 is 16 Channels GP338 is 128 Channels
- Power Supply: Provided through rechargeable battery - 7.5V
- DIMENSIONS: H x W x D (Radio footprint height excluding knobs)
With Standard High Capacity NiMH Battery: 137mm x 57.5mm x 37.5mm
With Ultra High Capacity NiMH Battery: 137mm x 57.5mm x 40.0mm
With NiCD Battery: 137mm x 57.5mm x 40.0mm
With LiIon Battery: 137mm x 57.5mm x 33.0mm
- WEIGHT: GP328 GP338
With Standard High Capacity NiMH Battery: 420 gm 428 gm
With Ultra High Capacity NiMH Battery: 500 gm 508 gm
With NiCD Battery: 450 gm 458 gm
With LiIon Battery: 350 gm 358 gm
- AVERAGE BATTERY LIFE @ 5/5/90 CYCLE Low Power High Power
With Standard High Capacity NiMH Battery: 11 hours 8 hours
With Ultra High Capacity NiMH Battery: 14 hours 11hours
With NiCD Battery: 12 hours 9 hours
With LiIon Battery: 11 hours 8 hours
- Sealing: Withstands rain testing per MIL STD 810 C / D / E and IP54
- Shock and Vibration: Protection provided via impact resistant housing exceeding MIL STD 810-C/ D / E and TIA/EIA 603
- Dust and Humidity: Protection provided via environment resistant housing exceeding MIL STD 810 C / D / E and TIA/EIA603

TRANSMITTER:
Frequency (MHz) 136-174 / 330-400 / 403-470 / 450-527
Frequency separation: Full bandsplit
Channel spacing: 12.5 / 20 / 25 kHz
Frequency Stability (-30°C to 60°C; +25°C Ref.): ±0.00025%
Power: 5W (VHF) / 4W (UHF)
Modulation limiting: ±2.5 @ 12.5 kHz, ±4.0 @ 20 kHz, ±5.0 @ 25 kHz
FM Hum & Noise: -40 dB
Conducted/Radiated Emission: -66 dBw
Modulation FOC Type: 12.5 kHz 11K0F3E / 25 kHz 16K0F3E
Audio Response (from 6 dB/octave pre-emphasis 300-3000 Hz): +1 to -3 dB
Audio Distortion: 3%

RECEIVER:
Frequency (MHz): 136-174 / 330-400 / 403-470 / 450-527
Frequency separation: Full bandsplit
Sensitivity (12dB SINAD) EIA: 0.25 µV
Intermodulation (EIA): 70 dB
Adjacent Channel Selectivity: 60 dB @ 12.5 kHz, 70 dB @ 25 kHz
Spurious Rejection: 70 dB
Rated Audio: 500 mW
Audio Distortion: 3%
Hum and Noise: -45 dB @ 12.5 kHz, -50 dB @ 25 kHz
Audio Response (300-3000 Hz): +1 to -3 dB
Conducted Spurious Emission: -57 dBm < 1 GHz, -47 dBm > 1 GHz, FCC Part 15
